5.3 Coplanar Lumped Elements

The group of lumped elements contains the most used elements. There are 6 elements in this group: Coplanar Interdigitated Capacitor (C_IDC), Coplanar Rectangular Spiral Inductor (C_RIND), Coplanar Thin-Film Resistor as series (C_TFR) or shunt resistor (C_TFG) and Coplanar MIM-Capacitor as series (C_MIM) or shunt capacitor (C_CAPLIN). Tables 5-3a and 5-3b show the coplanar lumped elements and their equivalent circuits.

In order to have a compatible coplanar port, a C_PORT element is also implemented into the coplanar palette. This element is used for layout generation only and has no effect on simulation results.

Coplanar lumped elements
Name	Physical	Equivalent Circuit
C_IDC Coplanar Interdigital Capacitor
C_RIND Coplanar Rectangular Inductor

Table 5-3a. Coplanar Lumped Elements in COPLAN for ADS and their equivalent circuit

COPLANAR LUMPED ELEMENTS
Name	Physical	Equivalent Circuit
C_MIM Coplanar MIM-Capacitor		Two coupled coplanar lines ¯ Distributed parameters ¯ Scattering Parameters
C_CAPLIN Coplanar MIM-Capacitor to Ground
C_TFR Coplanar Thinfilm Resistor
C_TFG Coplanar Thinfilm Resistor to Ground

Table 5-3b. Coplanar Lumped Elements in COPLAN for ADS and their equivalent circuit
